Chocolate mixer - 29684

For weighing and mixing before feeding the WA-FA 200/300 ball mill. With load cells for automatically adjusted ingredient dosing. Double-walled, stainless steel. With two mixer shafts (5.5 kW gear motors). With a 1.5 kW positive displacement pump, Model FPR210, for feeding the mixed product via a double-walled pipeline to the WA-FA ball mill. With an independent water heating system, PLC-controlled. Closed in the upper section by two hinged doors. With a stainless steel grille (protection against intrusion) and a safety limit switch. Connection: 10.6 kW. Voltage: 220-380, 50 Hz, 3-phase. Capacity: 1000 kg. Gear motor: 4 kW. Product pump: 1.5 kW. Water pump: 100 W. Heating resistor: 4000 W. Dimensions: 2510 x 2510 x 2510 mm 1370 x 1815 mm Brand new
